• FusionServer 1288H V7 (1288H V7) is a new-generation 1U 2-socket rack server designed for the Internet, Internet Data Center
(IDC), core IT services, cloud computing, virtualization, high-performance computing (HPC), enterprise or telecom service
applications, and other complex workloads.
• 1288H V7 features low power consumption, high scalability and reliability, easy deployment, and simplified management.

|
FusionServer 1288H V7 1U Rack Server in stock
Product Details:
| Place of Origin: | Beijing, China |
| Brand Name: | Xfusion |
| Model Number: | 1288H V7 |
Payment & Shipping Terms:
| Price: | $1,300.00 - $2,500.00/pieces |
|---|---|
| Delivery Time: | Normally 1-2 working days after PO and payment received |
| Payment Terms: | T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow |
|
Detail Information |
|||
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Type: | Rack | Processor Main Frequency: | 2.1GHz |
| Processor Type: | Intel Xeon | Product Name: | FusionServer 1288H V7 |
| Status: | Stock | Model: | 1288H V7 |
| Form Factor: | 1U Rack Server | MOQ: | 1 PCS |
| Memory: | 32 DDR5 DIMMs | Processor: | Intel Xeon |
| Warranty: | 3 Years | Dimensions (H X W X D): | 43.5 Mm X 447 Mm X 790 Mm |
| Chipset: | Emmitsburg PCH | ||
Product Description
Product Intrduction
FusionServer 1288H V7
There are many other kinds of configuration in stock , please contact what configuration you need . There are more than 90 million
inventory in warehouse , welcome to visit !
inventory in warehouse , welcome to visit !
FusionServer 1288H V7
|
MODEL
|
FusionServer 1288H V7
|
|
Form Factor
|
1U rack server
|
|
1U rack server
|
1 or 2 x 4th Gen Intel® Xeon® Scalable processors (Sapphire Rapids) with TDP up to 350 W per processor
|
|
Chipset
|
Emmitsburg PCH
|
|
Memory
|
32 x DDR5 DIMMs, with up to 4800 MT/s speed
|
|
Local Storage
|
Supports hot-swappable drives in the following configurations:
• 10 x 2.5ʺ drives (6–10 NVMe SSDs and 0–4 SAS/SATA drives, with a total number of 10 or less) • 10 x 2.5ʺ SAS/SATA drives/SSDs (2–4 NVMe SSDs and 6–8 SAS/SATA drives, with a total number of 10 or less) • 10 x 2.5ʺ SAS/SATA drives/SSDs • 8 x 2.5ʺ SAS/SATA drives/SSDs • 4 x 3.5ʺ SAS/SATA drives/SSDs • 32 x E1.S SSDs • 20 x E3.S SSDs* • 2 x M.2 SSDs |
|
RAID Support
|
RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection, RAID level migration, drive
roaming, self-diagnosis, and remote web-based configuration |
|
Network
|
Provides expansion capability of multiple types of networks
Supports OCP 3.0 NICs. The two FlexIO card slots support two OCP 3.0 NICs, which can be configured as required. Hot swap and PCIe 5.0 are supported |
|
PCIe Expansion
|
Provides 5 x PCIe slots, including 2 x FlexIO slots dedicated for OCP 3.0 NICs and 3 x PCIe slots, and 2 slots support PCIe 5.0
|
|
Fan Modules
|
Provides 8 x hot-swappable counter-rotating fan modules in N+1 redundancy
|
|
Power Supply
|
2 x hot-swappable PSUs in 1+1 redundancy mode. Supported options include:
• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC) • 1500 W AC Platinum PSUs • 1000 W (input: 100 V to 127 V AC) • 1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC) • 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC) • 1200 W –48 V to –60 V DC PSUs (input: –38.4 V to –72 V DC) • 2000 W AC Platinum PSUs • 1800 W (input: 200 V to 220 V AC or 192 V to 200 V DC) • 2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC) |
|
Management
|
The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault
diagnosis, automatic O&M, and hardware security hardening • The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0; provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management • It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies and realizes intelligent, automated, visualized, and refined management through the lifecycle |
|
Operating Systems
|
FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, CentOS, Oracle, Ubuntu,
Debian, openEuler |
|
Security Features
|
Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover
opening detection |
|
Operating Temperature
|
5ºC to 50ºC (41ºF to 122ºF), compliant with ASHRAE Classes A1, A2, A3, and A4
|
|
Certifications
|
CE, UL, FCC, CCC, VCCI, RoHS, etc
|
|
Installation Kit
|
Supports L-shaped guide rails, adjustable guide rails, and holding rails.
|
|
Dimensions (H x W x D)
|
Chassis with 3.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.)
Chassis with 2.5-inch drives: 43.5 mm x 447 mm x 790 mm (1.71 in. x 17.60 in. x 31.10 in.) |
